RTD with Welded Flange

Types:

Pt 100, Pt 200, Pt 500, Pt 1000, Cu 50 and Cu 53

Configuration:

Simplex / Duplex

Protection Tube Material:

SS 304 / SS 316 / SS 316 L / Hastealloy / Etc

Sizes:

16 mm to 28 mm and others are available on request.

Calibration Standard:

DIN 43760

Termination Type:

Head Assembly

Applications:

Available in both MI and Non MI configuration with connection heads and compressor fittings of various sizes.
